Machine Electricity Power: 30W (It has nothing to do with cutting or engraving performance,just electricity consumes)
Diode Power: 5.5-6W
Wave Length 455±5nm
Engraving Accuracy: 0.01mm
Focusing Method: Ffixed focus + sliding device
Protective Cover: The light filter cover on the protects the user’s eyes and prevents animals grabing the spot.
Operating Software: Compatible with GRBL, LightBurn, Benbox, GrblController, LiteFire,
etc.
Operatin System: Compatible with Apple system. Supported file formats NC, BMP, JPG, PNG, DXF and other image formats.
Data Transmission Method: USB connection
Power Supply: International universal standard power input: AC, 50/60HZ output: 12V 5A
Machine Weight: 3.0kg/ 6.61
Package Weight: 4.4kg/ 9.7
Package Size: 615*345*130mm/ 24.21*13.58*5.11in
Note:
●For detailed machine instructions, please refer to the manual for parameter settings.
●When operating the engraving machine, please install the protective cover. If it is not installed, you need to wear goggles.
● Please do not touch the emitter with your hand, or it may burn your hand.
● Please avoid b impact on the machine.
● Children under 14 are not allowed to use this product and children over 14 need adult supervision.
● The light engraving machine can not be directly applied to any mirror reflecting object, which may cause injury to the operator or burn the .
Package List:
1× X axis assembly
2× X shaft
2× Y shaft
1× Control box module set
3× Support feet
1× module set
1× Power Supply
1× USB cable
1× Tool Kit
1× Goggles
1× 10x10cm wood chip 3mm thickness
1× 10x10cm wood chip 10mm thickness
1× A4 size steel desktop protection pad
